Product Descriptio
chemical liquid tank trailer
liquid LPG, Butane ,Propane gas Storage/transport Tank Semi Trailer
trailer in this respect is very seriously, in terms of safety equipment, we provide the best performance of the most reliable highest configuration, accessories are made with domestic and international famous brands, safe and reliable.
The tank body of the bitumen tanker USES longitudinal welding, which is more reliable than normal ring welding, and the sealing is high. Even if it is bumpy on the road, the welding condition will not occur
Quick Details
fuel transport tanker | ||||
Dimension(Optional) | Axle No. | Rated Load (kg) | Tire No. | Tire Size |
10000-30000liters/10-30cbm | 2 | 40000 | 8 | 825R20 1000R20 1100R20 1200R20 12R22.5 (Other Size / Single Super Tire Contact with Supplier) |
30000-60000liters/30-60cbm | 3 | 60000 | 12 | |
Above 60000liters/60cbm | 4 | 75000 | 16 | |
Manufacture | Shandong （ANDA）JITONG Special Vehicle Manufacturing Co., Ltd. | |||
Wheel Base (mm) | 1310 | |||
leaf-spring Pcs | 10 | |||
Axle | 13/16/18 T | |||
Suspension | Heavy Duty Mechanic Suspension with Leaf Springs | |||
Main Beam Material | Q345B manganese plates, automatic submerged arc welded | |||
Brake System | Dual line braking system with automatic braking system/chambers | |||
Brake Air Chamber | Double Model | |||
Kingpin | 2' or 3.5' Interchangeable | |||
Landing gear | 28T loading capacity with 80T static lifting capacity. | |||
Tanker body | 5mm , sealing end: 6mm | |||
Brake System | Dual Lines Braking System With Automatic Air Chambers | |||
Brake Air Chamber | Four double and two single chamber | |||
Electrical System | 24V, 7core socket, lights according to European standards. | |||
Mainbeam Size | Upper plate | 14mm | ||
Lower plate | 16mm | |||
Mid Web | 8 mm | |||
Height | 500-520mm | |||
Tool Box | 1 box of standard tools | |||
Any parts fitted could according to clients request, contact us to get more. | ||||
Anda have more models fuel tank semi trailer for liquid cargo.
Material: Carbon steel, Aluminum alloy, Stainless steel
Volume: 28000 - 70000 liters
Compartments: 1 - 9
Axles: 2-4 axles
Click interested pictures below for more.
We support Customized design, it helps getting most suitable vehicles for you
We are manufacturer, provide customized service, design as the customers’ every request.
passed ISO9001 quality management system certification, 3C product certification, national safety production standardization secondary enterprise, has obtained A2 fixed pressure vessel (low temperature storage tank), C2 automobile tanker(low temperature), C3 tank container pressure vessel Production license, American Society of Mechanical Engineers ASME qualification certification, European ADR vehicle certification, China Classification Society tank container production approval certificate, national dangerous goods packaging, container production license, measurement management system certification, rated by the state as high-tech enterprise. And obtained more than 60 national patents.
Service
1.12months for main parts (engine, axle, body and beam, etc)
2. Technical Support by phone Whatsapp or email around the clock
3. Lifelong Parts Supports
Safety and Economic Shipping
Experienced teams choose the most suitable shipping way for different clients among containers, Roro and bulk shipment, balance safety and economic cost.
before shipping. We guarantee that all products have gone through strict inspection and are in good condition before shipment. We strive for 100% customer satisfaction on every sale we close.
