Product Description
Fence semi trailer Widely used, mainly suitable for medium and heavy and bulk cargo long-distance transportation, strong applicability, has become the first choice of long-distance freight vehicles.
Product parameter
Manufacturer | Shandong （ANDA）JITONG Special Vehicle Manufacturing Co., Ltd. |
Type | Fence cargo semi trailer |
Tare Weight | Approx. 6.2 T |
Dimension | 12400*2500*3800mm |
Loading Capacity | 30-100T |
Axle | 13T/16T, FUWA/BPW/SHENGRUN, etc |
Rim | 9.00*22.5/8.00-20/8.5-20 |
Suspension | Mechanical suspension(Germany type or America type) or Air suspension |
Leaf Spring | 90(width)mm*13(thickness)mm*10 layer(especial for exporting market) |
King pin | Jost brand 2.0 or 3.5 inch |
Spport leg | Jost brand two speed |
Main beam | Height: 500mm, upper plate is 14mm, middle plate is 8mm, down plate is 16mm; Material is Q345B steel |
Side beam | 16mm channel steel (Material is Q235B steel) |
Bottom Platform | 3mm checquered steel plate |
Side wall | 600 mm height (can be customized) |
Brake chamber | Wabco re 6 relay valve; T30/30+T30 spring brake chamber; two units of 45L air tanks |
ABS | Optional |
Twist locks | Optional |
Valve | Wabco valve (especial for exporting market) |
Light | LED Light (especial for exporting market) |
NORMAL PROCEDURE
1)cutting
fence semi trailer use the plasma cutting machine cut the steel to little parts use for suitable welding and splicing
2)welding
after steel cutting process the next step is welding .this process the main work is beam welding .the top plate-bottom plate and the middle plate will be welding together . this process will be use submerged arc welding process.this type of welding is very special .its exclusively used in I beam welding .after this welding process other parts of the trailer will be use different welding way for different steel-argon arc welding-electric arc welding-manual welding-gas welding and so on
3)blasting
this process is use for the first step of surface cleanness-stress relief-derusting before paiting .
4)electrophoresis coating
this process use for more detail surface cleanness
5)epoxy zinc primer spray coating
this process is the lasting one before paiting .after this process the trailer an be paiting
6)assembly
after all the process we have mationed .the last procedure of the trailer is assembly.this process all the parts will be assemly .it including tire-wheel rim-king pin-landing gear-suspension-spring leaf -brake chamber-air wiring-electricity wiring-brake system and so on
7)packing
The last process is packing .all the trailer use different packing way as customer requirment.after packing the trailer can be on the way to the customer
PRODUCT DETAILS
Packaging & Shipping
Main shipping way by Bulk Ship or RO-RO Ship:
FAQ
1.Does your company is a factory or trade company?
We have a factory ourself,we are on this business for 14 years in China.
2.Whats the qualify assurance we provided and how do we control quality?
Established a procedure to check products at all stages of the manufacturing processraw materials,process materials,validated
3. How do you transport the semi trailers and trucks?
We transport the vehicle by bulk or container. Our factory possess longterm cooperation with ship agency which can provide you lowest shipping fee.
4. Can you satisfy my special requirement?
Definitely! We are direct manufacturer and we have strong producing capacity and R&D capacity!
Welcome to leave your inquiry! Thank you!
