Cement tank trailer
---It is used for the transportation of dry powder materials such as fly ash,cement powder,lime powder and mineral powder, and pneumatic unloading. As is know to all, the remainder and discharge speed are very important to the bulk cement tank contaciner semi trailer .Under the pressure of 0.2MPa, the average unloading rate of the cement tanker is not less than 1.2t/min of our bulker and Remainder rate less than 0.05 tons .
ANDAJT AUTO powder tanker trailer
we selected famous brand of diesel engine, aircompressor, axle, suspension, Landing gear, we insure you will receive what you expect.
Product parameter
|
Dimension |
12000mm*2490mm*3990mm( Exact size depends on the final design) |
|
Tare weight kg |
About 11800KGS-13000KGS |
|
Tank capacity (CBM) |
30cbm-60cbm(Volume optional) |
|
Shape |
Optional(v or w shape) |
|
Compartments |
One or two compartment |
|
Tanker Body Material |
5mm or 6mm/Q235 carbon steel |
|
End Plate |
5mm or 6mm/Q235 carbon steel |
|
Rim |
8.00-20/8.5-20/8.8-20/9.0-22.5 China Brand |
|
Tire |
12R22.5/11R22.5/13R22.5/11.00R20/12.00R20( brand can be Optional) |
|
Engine |
Weichai 4105 Engine |
|
Manhole Cover |
500mm carbon steel or aluminum alloy manhole |
|
Bottom Valve |
3''/ 4” disc valve |
|
Discharging Valve |
Diameter is 3 or 4 inch |
|
Discharging Pipe |
4” rubber hose, 2 pcs, 6m/each |
|
Air compressor |
10 m3,12m3 |
|
Diesel Engine |
Weichai Huafeng, Tianhe 4102/4105 |
|
Main Beam |
Welding design or Special design, connected by bolts and nuts. Material:Q345 carbon steel
Height 500mm, |
|
Axle |
2 or 3 axles, BPW/FUWA brand(Optional) |
|
Landing Gear |
JOST(D200T)or China brand 28T(two speed) |
|
Brake System |
WABCO Valve with big chamber |
|
King Pin |
JOST 2.00 or 3.5 inch bolt-in king pin |
|
Suspension |
Mechanical suspension or Air suspension |
|
Leaf Spring |
90(W)mm×13(Thickness)mm×10(Layer) or 100mm×12mm×12 |
|
Rear ladder |
Dismountable |
|
Lights |
Turning Light, Side Marker Light, Tail Light |
|
Voltage |
24V |
|
Receptacle |
7 ways (7 wire harness) |
|
Painting |
Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
|
ABS |
Optional |
|
Accessories |
One standard tool box |
|
Shipping Terms |
By Bulk Cargo Carrier, RORO or 40HQ Containers |
We are professional in producing bulk cement tank trailer and engaged in technician developping this product for more than 10 years.
DETAILS
The tanker body and main beam: cutting by laser cutter and welding by laser positioning welding machine, good quality with beautiful welding.
The thickness are designed depend on the loading capacity of the trailer and road condition.
The common material is Q345, 5mm or 4mm thickness
Fuwa brand axles, the best brand in China, good quality and durable.
The common type is 13T, you can choose the number and capacity,model accroding to loading capacity of the trailer.
We also supply some quick wear spare parts for free for you:
1. Speed indicator
2. Diesel engine spare parts (gasket, filter)
3. Belt for engine, 1piece
4. Belts for compressor, 5 pieces
5. Air pressure gauge, 1 piece
6. 125mm clutch (butterfly) 1 piece
7. Manhole seals, 4 pieces
8. 5 inch tube bundle, 2 pieces
9. Air filter for compressor, 2pieces
10. 50mm ball valve for external source of gas
Factory
1.How about your price?
Although we are brand name products,but our prices are very favorable and competitive.?Customer from all over the world to
purchase our products, because our best price.
2.What's your payment?
Our Payment could be
(1) 100% T/T
(2) 30% in advance, others before shipment.
(3)Advance, others letter of credit.
3.Could you special design and produce for you？
Sure, we have all kinds of professional engineers,
Could design and produce special product according to customer requested.
Such as: special Size, special control, or OEM, etc.
4.Do you looking for Agent?
Yes, we're looking for the agent all over the world, please contact us for further discussion.
Welcome to leave your inquiry! Thank you!
