Product advantages of CO₂ tanker trailer

1. Design pressure reaches 0.7mpa, long non-destructive storage time and fast unloading speed

2. Lightweight design, the vehicle weight can reach 11580kg

3. Optional pneumatic suspension, running empty can reduce fuel consumption and improve fuel economy

4. Aluminum alloy guardrails and fenders, aluminum alloy wheels, light weight, beautiful appearance

5. LED in the whole car, high brightness, long service life

6. The whole vehicle adopts the reinforcement structure, the internal vacuum insulation cotton padding, the tank will not frost

7. ABS is used to prevent the vehicle from overturning, and there is a broken air brake at the end of the operation box, and the vehicle cannot be started when the valve box is not closed, which improves the safety of the vehicle.

8. The rear operation box is made of aluminum alloy, the height is reduced, which is easy to operate

9. Adopt the international advanced technology process, good quality and economic price.

For 40ton total weight liquid CO₂ tanker trailer

Tank Parameters
Tanker volume		27.2 m³	Curb weight		11580kg
Suspension	- mm 2034 mm	Departure angle	- ° - °	Tanker speed limit	Driving	≤80 Km/h
Size	12800 2500 3450 mm			Fully loaded	Traction	16000kg
Wheelbase	6870+1310+1310 mm				Axle	24000 kg
medium	Liquid oxygen	Ambient temperature	-40 ~50	Design service life		/
Tank body
parameter	Capacity	27.2 / 7.2 m³	inside diameter	1800/2000 mm	Total length of tank	11518 mm
	design pressure	0.80/-0.1MPa	Weight	6431 kg	Design service life	10 years
	set tempreture	-157/50 °C	Filling amount	≤1026kg/m³	Work pressure	<0.75/-0.1 MPa
	Welding joint coefficient	1.0/0.85	Corrosion allowance	0/0 mm	/	/
Structure type	Main structure type		Double layer	Insulation method	High vacuum multilayer insulation
Test	Pressure test pressure		1.04 MPa	Air tightness test pressure		0.8 MPa
	Non-destructive testing		RT,MT,PT	Non-destructive testing ratio		100%,20%
	Pressure after gas replacement		0.07 MPa	Oxygen content in tank		2%
