CNG tank / 12 tubes container is a new professional storage and transportation equipment for Compressed Natural Gas(CNG), the features are flexible, convenient, efficient, it is the latest means of mass transportation specialized for compressed natural gas, applies to road transport compressed natural gas (CNG) (does not apply to the transportation of liquefied gases and dissolved gases).

1. Function:

This type CNG tube transport truck tank semi trailer, can store and trasnport CNG, they are designed, manufactured, inspected and accepted according to ISO11120 Cylinder-design, structure and test of seamless and reusable steel tube with a capacity between 150L to 3000L.

2. Application:
1] For CNG transportation from mother station/ gas reserve to daughter station.

2] For CNG transportation to places where pipeline network hasn't been built.

3] For CNG transportation to places where can't reach existing distribution system etc.

3.Technical Parameters for High-Pressure Compressed Natural Gas CNG Tube Transport Truck

Tank Semi Trailer:

8-tube bundle container CNG tank semi trailer
Tube Bundle Container		Cylinder
Item	Data	Item	Data
Tare weight	30740Kgs (include chassis)	Working pressure	25MPa
Filling quality	4410Kg	Working temperature	-50~65℃
Total weight	35150Kgs (include chassis)	Main material	30CrMoLX
Major risk category	2.1	cylinder QTY	8
UN code	1049	Total volume	19.6M3
Filling medium	CNG	Pressure for water pressure test	37.5MPa
Gas tightness test pressure	25Mpa	Dimension(mm)	559x11570

Kindly Note:

Above parameter is just for your reference, Consider different countries have different road safety rules, different regulations, different road conditions, we could customize different kinds of CNG tank semi trailer according to your special situation.

Advantages for CNG Tube Transport Truck Tank Semi Trailer:

1] Seamless structure provide the most reliable guarantee for operation safety.

2] The container have large volume capacity which can reduce transportation turnover and improve the working efficiency.

3] Large size sturcture allows for a reduction in the number of valves and few knots which without much piping, in order to reduce the risk of leakage.

4] The whole CNG tube transport truck tank semi trailer have light weight which can reduce the tractor power and the cost of investment.

5] The CNG tube transport truck tank semi trailer have the gas supply device which can be directly provided the natural gas fuel for energy saving.
